VACUUM CIRCUIT BREAKER
AK Transcharger Pvt Ltd is providing CGL make indoor vacuum circuit breakers (VCB) as well as outdoor porcelain clad VCBs in India. AKTPL offer outdoor metal clad VCBs Up to 36KV, 2000Amp.
AKTPL also offer outdoor metal clad VCBs (KIOSK). There is no need to modify the associated relays, current transformer / potential transformer, bus bar chamber and instrument cubicle on the existing panel.
| DESCRIPTION | RATED VOLTAGE | RATED CURRENT | BREAKING CAPACITY | STANDARDS |
| INDOOR TYPE | ||||
| 12kV VCB (Calix) | Up to 12 kV | Up to 4000 A | Up to 50 kA | IEC,IS |
| 36 KV VCB (Felix) | Up to 36 kV | Up to 2000 A | Up to 40 kA | IEC,IS |
| Vertical Isolation VCB | Up to 12 kV | Up to 1250 A | Up to 20 kA | IEC,IS |
| Retrofit Solution | Up to 12 kV | Up to 2000 A | Up to 40 kA | IEC,IS |
| OUTDOOR TYPE | ||||
| Porcelain Clad VCB | Up to 36 kV | Up to 2000 A | Up to 40 kA | IEC,IS |
| Metal Clad VCB – KIOSK | Up to 36 kV | Up to 2000 A | Up to 40 kA | IEC,IS |
GAS INSULATED SWITCHGEAR
CGL offer latest technology GIS. The Product comes with flexible SF6 gas insulated modules of various equipments to suit different network configurations.
As the world is moving towards highly compact and reliable power Transmission and Distribution equipment, GIS is emerging as the best solution for Power Transmission and Distribution. CG offers latest technology GIS. They are now found affordable in place of AIS.
The Product comes with flexible SF6 gas insulated modules of various Equipment to suit different network configuration
| DESCRIPTION | TYPE | RATED VOLTAGE | STANDARDS |
| MV GIS | |||
| 36kV GIS | Arista | Up to 36 kV | IEC,IS |
| HV GIS | |||
| GIS – 3 Phase Enclosed Compact | GT01 | 72.5 to 145 kV | IEC |
| GIS – 1 Phase Enclosed | GAI1, GAI3 | 72.5-170 kV, 245-300 kV | IEC |
GAS CIRCUIT BREAKER
CGL Providing GCBs is ranging from 24 kV to 765 kV. We are Providing 800 kV 3150 Amp, 50 kA GCB with Spring-Pneumatic Mechanism. We have also providing breakers for 40 Deg application and 60 Hz frequency requirement.
CGL also offer SF6 gas circuit breakers (GCB) in India which is operating satisfactorily. We developed 800 kV 3150 a, 50 kA GCB with Spring-Pneumatic Mechanism indigenously with our R & D efforts. We have also developed breakers for 40 Deg application and 60 Hz frequency requirement. Our manufacturing units are certified with ISO 9001, ISO 14000 for environment control and OSHAS 18000.
| DESCRIPTION | RATED VOLTAGE | RATED CURRENT | BREAKING CAPACITY | STANDARDS |
| INDOOR TYPE | ||||
| 36 KV Indoor SF6 GCB | Up to 36 kV | Up to 2000 A | Up to 40 kA | IEC,IS |
| OUTDOOR TYPE | ||||
| 36 KV Outdoor GCB | 63 KV | Up to 3150 A | Up to 25 kA | IEC |
| 72.5 KV Outdoor GCB | 72.5 KV | Up to 3150 A | Up to 40 Ka | IEC |
| 145 KV Outdoor GCB | 145 KV | Up to 3150 A | Up to 40 kA | IEC |
| 170 KV Outdoor GCB | 170 kV | Up to 3150 A | Up to 40 kA | IEC |
| 245 KV Outdoor GCB | 245 kV | Up to 3150 A | Up to 40 Ka | IEC |
| 420 KV Outdoor GCB | 420 kV | Up to 3150 A | Up to 50 kA | IEC |
| 800 KV Outdoor GCB | 800 kV | Up to 3150 A | Up to 50 kA | IEC |
UNITISED SUBSTATIONS
A Unitized Substation (USS) is a nutshell product comprising of various substation equipments, housed inside a metal enclosure, such as a step down transformer, a Vacuum Circuit Breaker (VCB) or a Ring Main Unit (RMU) on High Voltage (HV) side and Low Voltage (LV) distribution panel in LV side compartment. The product is highly reliable, safe, user friendly and ready to use with appealing aesthetics.
| DESCRIPTION | HT RATED VOLTAGE | TRANSFORMER RATING | STANDARDS |
| OUTDOOR TYPE | |||
| Radix Series | Up to 12 kV | Up to 1600 KVA | IEC,IS |
